| Series | T/LL130 | T/LL350 | T/LL200 | T/LL136 | T/LL171 |
 |  |  |  |  |
|
| Type | Capacitance | Capacitance | Hydrostatic | Capacitance | Capacitance |
| Media | Check specs | Check specs | Check specs | Check specs | Check specs |
| Connection | 4-way Dephi Packard | 18AWG XPE flying leads | 4-way Dephi Packard | 4-way Dephi Packard | 4-way Dephi Packard |
| Output | Resistive, Current, PWM | Resistive, Voltage,Current | Voltage, Current | Resistive, Voltage, PWM | Current |
|
|
T/LL130 – Capacitance Liquid Level SensorA liquid level sensor which provides a continuous output of tank contents in either resistance, voltage or PWM formats. Available for tank depths between 200mm and 2000mm it can be used in any liquids compatible with the wetted parts. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
|
|
T/LL350 – Capacitance Liquid Level SensorThe Model T/LL350 series provides a continuous level measurement of tank contents and offers a choice of voltage, resistance or 4-20mA outputs. The dual probe design allows the sensor to continuously self calibrate and detect, for example, different fuels, and will recalibrate the output to compensate for differing dielectric constants. Therefore, if a tank is filled with conventional diesel and then bio-diesel, the sensor automatically calibrates to give a corrected output without the need for the user’s intervention. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
|
T/LL200 – Hydrostatic Liquid Level SensorThe Model T/LL200 series is designed for use in tanks requiring continuous level measurement of their contents and provides a voltage or 4-20mA output suitable for connecting into plc or process related applications. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
|
|
T/LL136 – Race Fuels Level SensorA liquid level sensor specifically for race fuels which provides a continuous output of tank contents in either resistance, voltage or PWM formats. Available for tank depths between 200mm and 600mm it can be used with most aggressive fuel additives. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
|
T/LL 171 – Capacitance Liquid Level SensorT/LL171 is a vertically mounted sensor designed for use in fuels and water based liquids such as engine coolant. Occupying a tiny footprint, the sensor is available in lengths between 90 and 500mm long. Offering good levels of accuracy at elevated temperatures, the T/LL171 has an integral Packard style connector. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
