| SERIES | S82 | S86 | S81 | S85 | S87 |
 |  |  |  |  |
|
| TYPE | Capacitance | Capacitance | Capacitance | Capacitance | Capacitance |
| FLUID MEDIA | Fuels (oil/diesels) | Fuels(oil/diesels) | Coolants/Water | Coolants/Water | Coolants/Water |
| MOUNTING | Horizontal | Horizontal | Horizontal | Horizontal | Horizontal |
| SERIES | S98 | S99 | ||
 |  | |||
| TYPE | Capacitance | Capacitance | ||
| FLUID MEDIA | Coolants/Water | Fuels (diesel/oil) | ||
| MOUNTING | Horizontal | Horizontal |
|
|
S82 – Capacitance Liquid Level SwitchS82 is a horizontally mounted switch for sensing diesel/oil levels. Fitted with a DIN bayonet style connector all models have an inbuilt time delay to reduce the risk of intermittent switching through fluid turbulence and a wide selection of switching outputs. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
|
|
S86 – Capacitance Liquid Level SwitchS86 is a horizontally mounted switch for sensing diesel/oil levels. Fitted with a Packard connector all models have an inbuilt time delay to reduce the risk of intermittent switching through fluid turbulence and a wide selection of switching outputs. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
|
|
S81 – Capacitance Liquid Level SwitchS81 is a horizontally mounted switch for sensing water/coolant levels. It is fitted with a DIN bayonet style connector and hasan inbuilt time delay to reduce the risk of intermittent switching through fluid turbulence and a wide selection of switching outputs. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
|
|
S85 – Capacitance Liquid Level SwitchS85 is a horizontally mounted switch for sensing water/coolant levels. Fitted with a Packard connector all models have an inbuilt time delay to reduce the risk of intermittent switching through fluid turbulence and a wide selection of switching outputs. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
|
|
S87 – Capacitance Liquid Level SwitchS87 is a horizontally mounted switch for sensing water/coolant levels. This product differs from the S85 by offering flying leads as the means of connection with the customer’s own choice of plug or receptacle optionally available. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
|
|
S98 – Capacitance Liquid Level SwitchS98 is a horizontally mounted switch for sensing water/coolant levels. The difference between it and the S85 is that the S98 outputs two distict voltages dependent upon if it sees a safe or an alarm condition. For example, the output might be set at 1V out for the safe condition and 4V out at alarm condition. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
|
|
S99 – Capacitance Liquid Level SwitchS99 is a horizontally mounted switch for sensing diesel/oil levels. The difference between it and the S86 is that the S99 will output two distinct voltages dependent upon it seeing a safe or an alarm condition. For example, the output can be set to 1V out in the safe condition and 4V out in an alarm condition. |
|
| Technical Specifications [pdf] | Installation Guide [pdf] | |
|
|
||
